Jewelry Spot Welder with CCD 200W 60 Joules 220V Spot 0.3-2.5mm Microscope LED Light Laser Jewelry Spot Welding Machine for Rings Pendants Bracelets Platinum 24K Gold

The Jewelry Laser Welder Machine Offers A 0.3-2.5mm Spot Size For Precise Welding, Making It Ideal for Intricate Tasks In Gold, Silver, And Platinum. High-Speed Laser Welding at up to 20hz Ensures Efficiency For Both Small And Large Jewelry Projects. This Laser Welding Machine For Metal And Spot Welding Machine Provides Exceptional Accuracy And Performance.

Parameters

• Laser Power: 200W
• Energy:60J
• Laser Wavelength: 1064nm
• Pulse Width: 0.1-20ms
• Spot Size:0.3-2.5mm
• Laser Frequency: 0-50Hz
• Spot Adjustment Range: 0.2-2mm.
• Voltage:220V 1 Phase(Voltage Transformer is needed if 110V)
• Cooling System:Air Cooling
• Rated Power :6.5KW
• Packaging Size:1100*370*1300mm

Features

• 【High-Power Laser Efficiency】 The 200W jewelry laser welder offers a maximum laser power of 200W and pulse energy of 60J, providing precise and efficient welding for various metals. With a laser wavelength of 1064nm and an adjustable pulse width from 0 to 20ms, it ensures smooth and beautiful weld joints, making it ideal for jewelry, dental, and precision electronic applications.
• 【Advanced Cooling System and Stability】 Featuring a built-in water cooler and a digital control system, this spot welder machine maintains high stability and a long service life. The ceramic laser cavity offers high photoelectric efficiency, temperature resistance, and corrosion resistance, ensuring consistent performance for demanding tasks such as spot welding jewelry and repairing seams.
• 【Enhanced Precision with CCD Image Sensor】 The integrated microscope with CCD configuration allows for precise observation of welding joints on the screen, facilitating micro-size processing. The adjustable binocular pupil distance and rotatable direction enhance user convenience, making it perfect for detailed work on gold and silver jewelry, glasses frames, and electronic components.
• 【Versatile Welding Modes and Easy Operation】 This gold laser welder supports multiple welding process modes with adjustable pulse width, frequency, and spot size, ensuring strong applicability for various tasks. The universal wheel design allows easy movement, and the automatic water pumping with one-button start simplifies operation, catering to diverse needs in the arts and crafts and medical equipment industries.

Application

• Wide Range of Applications: Widely used in mobile communications and arts and crafts, this jewelry laser welder meets high precision standards. Perfect for welding dental pieces, sporting goods, golf heads, and medical equipment.
• Permanent Jewelry Welding: It serves as a welder for permanent jewelry and a robust permanent jewelry welder machine for diverse industrial applications, ensuring high precision and reliability.

Warranty

• 1 Year Warranty for the Whole Machine,2 Years Warranty for the Laser Source. CE & FDA Certificate.
• After Sales Center in NY, US. Offer Remote Assistance for Operation Issues, Lifetime Online Technical Support.
• Free Shipping by Air to Door Around 7 to 10 Days. No Import Duty for American Customers.
