Fiber Laser Cutting Machine 1500/2000W Laser Cutter and Engraver Working Area 300*300mm for Gold Silver

Advantages:

• Ultra-high precision linear motor module;
• Compact structure & lower loss;
• High position accuracy and re-positioning accuracy.
• Higher speed and acceleration;
• Excellent follow-up performance;
• Safe, reliale, long service life.
• European CE Standard Protective Glass

Parameter:

• Working Area:300*300mm
• Fiber Laser Power: 1000W-2000W
• Laser Wavelength: 1064nm
• Beam Quality:＜0.373mrad
• Max Cutting Accuracy:±0.03mm
• Repeated Positioning Accuracy:±0.01mm
• Max Operating Speed:30m/min
• Max Cutting Speed: 30m/min Depending on Material
• Transmission Type:Precison Dual Ball Screw Transmission
• Drving Systems:Servo motors
• Cutting Depth:Depends on Laser Power and Materials
• Assit Gas:Compressed Air,Oxygen,Nitrogen
• Cooling Method:Industrial circulation water chiller
• Aiming and Positioning :Red Dot
• Working Voltage:220/380V 50/60HZ(Transformer Avaiable)
• Machine Dimension/Net Weight:1839*1205*2045mm 600kg
• Packing Dimension/Gross Weight:1800*1500*1970mm 850kg

Features:
[Wide Application]Machine is suitable for Ultra-high precision Cutting ,Such as Carbon steel ,Manganese Steel,Stainless Steel, Color steel plate,Foliate Lamina Aluminum Plate, Aluminum Alloy,Brass,Copper,Titanium Plate
[Professional Laser Cutting Control System]Software with super anti-interference ability and superior stability.Aviation industry extruded aluminum beam, light weight, good rigidity, high precision, stable structure, not easy to deform.
[Smooth Surface without burrs]Engraving and cutting in one machine.Fast Speed .High Efficiency.High Precision.Equip with Professional parts.
Configuration:
MAX laser source, Raytools BM110 autofocus cutting head, Teyu chiller, CypOne control system (simplified version), SMG guide rail and ball screw drive, Leadshine servo system (400W motors for X and Z axes, 750W motor for Y axis); viewing window features CE-certified laser protective glass.
Warranty and Delivery:

• 1 Year Warranty for the Whole Machine,2 Years Warranty for the Laser Source. EU,CE & FDA Certificate.
• After Sales Center in NY, US. Offer Remote Assistance for Operation Issues, Lifetime Online Technical Support.
• Free Shipping by Sea&Truck to Door Around 45 to 60 Days. No Import Duty for American Customers.
• Remote technical pre-sales and after-sales service.Provide free sample processing service,which can cut according to the customers drawing,and provide video.
