US STOCK Pneumatic Dot Peen Marking Machine 100W Pneumatic Dot Peen Metal Engraving Machine Engraving Size 80x40mm/120x50mm/150x80mm

This metal engraving machine uses a dot peen system for accurate, automatic engraving of fixed characters, serial numbers, VINs, dates, and graphics on metal surfaces.

Parameters

• Model: Z-MARKING-08040/Z-MARKING-12050/ZS-MARKING-15080
• Marking Depth:0.02-1mm(depending on material)
• Marking Speed: 3-5 Characters/S
• Marking Range: : 80*40mm,120*50mm,150*80mm
• Power Supply: AC110V/220V 50HZ
• Air Pressure: 0.4-0.5Mpa for Z-Marking 08040 and Z-Marking 12050,0.4-0.6Mpa for ZS-Marking 15080
• Air Consumption: 3L/S
• Power Consumption: 100W
• Operating Temperature: 1-40°C
• Relative Humidity <90%
• Net Weight: 10kg for Z-Marking 08040,11kg for Z-Marking 12050,17kg for ZS-Marking 15080
• Operating Temperature:1-40°C
• Number of Marking Needle:Three Marking Needle

Advantages

• 【Portable and Efficient】Pneumatic metal engraving machine is highly portable,  making it perfect for on-site metal tag engraving. With a marking depth of 0.02-1mm and a speed of 3-5 characters per second, it ensures precise and efficient engraving.
• 【Advanced Touch Screen Control】The 100W dot peen marking machine features a 7-inch built-in touch screen controller,eliminating the need for a computer. deal for automotive and electronics industries, it allows easy adjustment of parameters and ensures high-quality, deep, and permanent marks.
• 【Secure and Stable Marking】Portable handheld dot peen marking machine can be firmly attached to metal surfaces, providing stability during marking. Suitable for large machinery and equipment, it delivers consistent and accurate engravings.

Application

Automatic Engrave the Beautiful Marking-Can be Used for Marking Fixed Character,Serial Number,VIN,Date,Graphics and other Marks.

Warranty

• 1 Year Warranty for the Whole Machine
• After Sales Center in NY, US. Offer Remote Assistance for Operation Issues, Lifetime Online Technical Support.
• Free Shipping by Air to Door Around 5 to 7 Days. CA,KY, Local Warehouse,No Import Duty for American Customers.
